Multi core yooj yim ceg cable
GJPFXJH

1-Tight buffer

2-Inner Sheath

3-Tus tswv cuab muaj zog

4- Tshem tawm cov cim taw qhia

Khoom nta

Zoo heev mechanical thiab ib puag ncig kev ua haujlwm

Tag nrho cov txheej txheem dielectric thiab qhuav core txhim kho kev ua haujlwm thiab huv hauv kev xa tawm

Me txoj kab uas hla, lub teeb yuag, me me nyob qhov chaw

FRP ua rau cable muaj zog nro thiab tiv thaiv khoov zoo

Cov ntaub ntawv xa nrog kev ntseeg siab, tus nqi qis, yooj yim rau kev sib txuas, thiab lwm yam

Distribution cable fiber optic nyob rau hauv Multi core yooj yim ceg cable yuav muab faib ua ob peb ywj siab kho qhov muag units kom yooj yim kev twb kev txuas thiab installation

Daim ntawv thov

Sab hauv kab rov tav thiab ntsug kab

Fiber Transmission Performance

Cabled Optical fiber ntau

62,5 ua

(850nm / 1300nm)

50ua um

(850nm / 1300nm)

G.652

(1310nm / 1550nm)

G.657

(1310nm / 1550nm)

Max attenuation (dB/km)

3.5/1.5

0.4/0.3

Tus nqi (dB/km)

3.0/1.0

0.36/0.22

Technical Specification

Hom kab	Fiber suav	Tensile zog (N)		Flattening quab yuam (N / 100mm)		Yam tsawg kawg bending radius (mm)		Optical cable txoj kab uas hla (mm)
Hom kab	Fiber suav	luv luv	Lub sij hawm ntev	luv luv	Lub sij hawm ntev	Thaum nruab	Tom qab installation	Optical cable txoj kab uas hla (mm)
GJPFXJH	4	500	250	1000	500	20D	10D	7.5
GJPFXJH	8	500	250	1000	500	20D	10D	8.0
GJPFXJH	12	500	250	1000	500	20D	10D	9.0
GJPFXJH	24	500	250	1000	500	20D	10D	10.5

Sau ntawv

1. D qhia txog txoj kab uas hla ntawm lub cable;

2. Cov kev ntsuas saum toj no yog tus nqi raug;

3. Cov kab tshwj xeeb. tuaj yeem tsim raws li cov neeg siv khoom xav tau;

Environmental yam ntxwv

• Kev thauj mus los / cia kub: -20 degree rau +70 degree

Cable Packing

• Ntev ntev: 1,000m lossis 2,000m; lwm qhov ntev kuj muaj.
• Cov cables tau ntim rau hauv cov nruas ntoo, lossis ua raws li cov neeg siv khoom xav tau.

Kev pabcuam

• Peb cov khoom siv npog ntau hom optical cables, suav nrog ib leeg-hom optical cables, ntau hom optical cables, optical fiber splitters, thiab lwm yam., uas yog dav siv hauv kev sib txuas lus, tes hauj lwm, cov chaw zov me nyuam thiab lwm yam. Peb cov khoom siv kho qhov muag cable muaj kev sib kis tau zoo, ua haujlwm ntev thiab ruaj khov, thiab tuaj yeem ua tau raws li qhov xav tau ntawm qhov chaw sib txawv.

Tus khub

FAQ

Q: Multi core yooj yim ceg cable yog dab tsi?

A: Yog vim li cas vim li cas yooj yim branching optical cables hu ua "yooj yim branching" yog vim hais tias lawv muaj peev xwm branching yam ntxwv. Cov kab hluav taws xob kho qhov muag yuav tsum tau ntsuas qhov tseeb thiab kev npaj ua ntej ntawm qhov ntev ntawm txhua ntu thaum xaim, thaum yooj yim branching optical cables tuaj yeem hloov tau yooj yim branched qhov xav tau yam tsis xav tau kev npaj ua ntej nruj. Qhov kev hloov pauv no ua rau kev xaim yooj yim dua, tso cai rau cov ceg ntoo ntawm qhov chaw sib txawv raws li qhov xav tau, ua rau nws tsim nyog rau ntau qhov chaw sib txuas sib txuas.

Q: Dab tsi yog Extract point marker?

A: Cov txheej txheej sab hauv ntawm cov kab hluav taws xob kho qhov muag muaj cov qauv elliptical, thiab cov ntsiab lus convex ntawm sab nrauv ua haujlwm raws li cov cim taw qhia thinnest rau cov khoom siv kho qhov muag, ua rau nws yooj yim rau tev tawm cov ceg.

Q: Dab tsi technologies thiab cov cuab yeej yuav tsum tau rau lub installation thiab txij nkawm ntawm yooj yim branching optical cables?

A: Txhim kho yooj yim branching optical cables yuav tsum tau tej fiber optic cabling thiab splicing cov tswv yim, thiab tej zaum kuj yuav tsum tau tshwj xeeb fiber optic cabling cov cuab yeej thiab cov cuab yeej.
